Oxford Flow High Pressure Gas Regulator IHF Series

Brand	Oxford Flow
Model	IHF Series High-Pressure Gas Regulator
Technical Specifications	Max Inlet Pressure: Up to 100 bar Max Outlet Pressure: Up to 99.5 bar Leakage: Bubble tight Lock-up Class: SG 5 Accuracy Class: AC 0.5 Performance & Flow Capacities: DN100 (4”): Cv 63 / 1,701 KG DN150 (6”): Cv 142 / 3,834 KG DN200 (8”): Cv 252 / 6,804 KG DN300 (12”): Cv 567 / 15,309 KG
Gas	Non-corrosive Industrial Gases
Dimension & Weight	Sizes: DN100 – DN300 / Approx. Weight: 85 – 450 kg (depending on size)
